Nut, open, knurled, steel, diameter=5,9, M4, L=10, min. clamping range=0,5
MT107405
Nut manufactured in steel of the type open and with reduceret collar. The diameter is 5,9mm, the length is 10mm, and the tread size is M4. The minimum clamping range is 0,5mmand the maximum clamping range is 1,5mm. Special products can be delivered on request, if you cannot find the right product in our standard range.
B
6,75
Shape
Knurled
Tread size
M4
Collar
Reduced
Material
C10C
Material type
Steel
Surface finish
Electro zinc plated
r, max.
8
Series
FTR/C
Type
Open
X
0,5
Diameter in mm
0
Torque in N.m
4
Hole diameter in mm
6
L
10
Clamping range, min.
0.5
Clamping range, max.
1.5
Tensile strenght, axial
7300
Long description
Nut manufactured in steel of the type open and with reduceret collar. The diameter is 5,9mm, the length is 10mm, and the tread size is M4. The minimum clamping range is 0,5mmand the maximum clamping range is 1,5mm. Special products can be delivered on request, if you cannot find the right product in our standard range.
