Complete hose clamp, stainless steel, Diameter range: 79-85mm, torque= 30Nm, Load class= High
MT100177
Complete hose clamp manufactured in stainless steel. Diameter range is 79-85mm. The torque is 30Nm. The load class is High. Hose clamp with bolt.
*It is recommended to apply 75% of the maximum pressure and torque values. We offer many different products, so if you cannot find a product which meet your requirements, then please contact us.
Load class
High
Tread size
M8
Material
AISI 304
Material type
Stainless steel
Material execution
W4
RoHS
Yes
Series
Supra Heavy-Duty
Wrench
13
Pressure, max.
20
Type
Screw adjusting
Breakage load (Ultimate stress) in kg
0
Diameter, min.
79
Diameter, max.
85
Torque in N.m
30
Thread length in mm
0
Thickness in mm
0
Long description
Complete hose clamp manufactured in stainless steel. Diameter range is 79-85mm. The torque is 30Nm. The load class is High. Hose clamp with bolt.
*It is recommended to apply 75% of the maximum pressure and torque values. We offer many different products, so if you cannot find a product which meet your requirements, then please contact us.
