Gas spring, stainless steel, M8 thread, stroke length = 133 mm, force = 400 N
MT101956
Gas spring manufactured in stainless steel with M8 thread for mounting the end fittings. Stroke length is 133 mm and the force is 400 N. The mounting length is 320 mm. We can deliver a wide range of products on request. Please contact us for more information.
End damping
Both directions
Fitting, cylinder
Fitting, piston
Material type
Stainless steel
Mounting, cylinder side
M8
Mounting, piston side
M8
Oil chamber
No
Progression
30
Valve
Yes
Cylinder diameter in mm
23
Force in N
400
Mounting length in mm
320
Stroke length
133
Piston diameter
10
Long description
Gas spring manufactured in stainless steel with M8 thread for mounting the end fittings. Stroke length is 133 mm and the force is 400 N. The mounting length is 320 mm. We can deliver a wide range of products on request. Please contact us for more information.
