Levelling foot, stainless steel, fixed threaded spindle, M8, base diameter = 40 mm
MT111522
Levelling foot in stainless steel with fixed threaded spindle and M8 thread. Base diameter = 40 mm. The levelling foot can not be mounted to floor. We can deliver a wide range of products on request. Please contact us for more information.
Colour
Black
Fixing to floor
No
Base material
TPE
Tread size
M8
Rubber pad
No
Shore standard
Shore A
Material type
Stainless steel
Foot height
16
Wrench
0
Type
Fixed threaded spindle
Diameter in mm
40
Thread length in mm
36
Height in mm
52
Hardness in °
80
Maximum load in kg
300
Long description
Levelling foot in stainless steel with fixed threaded spindle and M8 thread. Base diameter = 40 mm. The levelling foot can not be mounted to floor. We can deliver a wide range of products on request. Please contact us for more information.
